Antenna Design for Mobile Devices (Wiley – IEEE)

De (autor)
Notă GoodReads:
en Limba Engleză Carte Hardback – 17 Feb 2017
Expanded and updated, this practical guide is a one–stop design reference containing all an engineer needs when designing antennas

Integrates state–of–the–art technologies with a special section for step–by–step antenna design
Features up–to–date bio–safety and electromagnetic compatibility regulation compliance and latest standards
Newly updated with MIMO antenna design, measurements and requirements
Accessible to readers of many levels, from introductory to specialist
Written by a practicing expert who has hired and trained numerous engineers
