High Frequency Continuous Time Filters in Digital CMOS Processes

Autor Shanthi Pavan, Yannis Tsividis
en Limba Engleză Hardback – 29 feb 2000
There is an ever increasing trend towards putting entire systems on a single chip. This means that analog circuits will have to coexist on the same substrate along with massive digital systems. Since technologies are optimized with these digital systems in mind, designers will have to make do with standard CMOS processes in the years to come. We address analog filter design from this perspective. Filters form important blocks in applications ranging from computer disc-drive chips to radio transceivers. In this book, we develop the theory and techniques necessary for the implementation of high frequency (hundreds of megahertz) programmable continuous time filters in standard CMOS processes. Since high density poly-poly capacitors are not available in these technologies, alternative capacitor structures have to be found. Met- metal capacitors have low specific capacitance. An alternative is to use the (inherently nonlinear) capacitance formed by MOSFET gates. In Chapter 2, we focus on the use of MOS capacitors as integrating elements. A physics-based model which predicts distortion accurately is presented for a two-terminal MOS structure in accumulation. Distortion in these capacitors as a function of signal swing and bias voltage is computed. Chapter 3 reviews continuous-time filter architectures in the light of bias-dependent integrating capacitors. We also discuss the merits and demerits of various CMOS transconductance elements. The problems encountered in designing high frequency programmable filters are discussed in detail.
Citește tot Restrânge

Toate formatele și edițiile

Toate formatele și edițiile Preț Express
Paperback (1) 61300 lei  6-8 săpt.
  Springer Us – 15 apr 2013 61300 lei  6-8 săpt.
Hardback (1) 61929 lei  6-8 săpt.
  Springer Us – 29 feb 2000 61929 lei  6-8 săpt.

Preț: 61929 lei

Preț vechi: 72858 lei
-15% Nou

Puncte Express: 929

Preț estimativ în valută:
10959 12850$ 9624£

Carte tipărită la comandă

Livrare economică 31 ianuarie-14 februarie 26

Preluare comenzi: 021 569.72.76

Specificații

ISBN-13: 9780792377733
ISBN-10: 0792377737
Pagini: 214
Ilustrații: XXIV, 214 p.
Dimensiuni: 155 x 235 x 20 mm
Greutate: 0.52 kg
Ediția:2000
Editura: Springer Us
Colecția Springer
Locul publicării:New York, NY, United States

Public țintă

Research

Cuprins

Mos Capacitors: Modeling & Potential as Integrating Elements in Continuous Time Filters.- A Review of Integrator Architectures.- Time Scaling in Electrical Networks.- Filter Design.- Filter Testing and Measured Results.- Applications of Scaling to Other Filter Techniques.- Tuning in Continuous-time Filters.
