Electrical and Thermal Flows across Parallel Plates

Autor Reza Haj Mohammad Jafar, John R. Dryden
en Limba Engleză Paperback – 29 iul 2012
With the recent progress of MEMS technology, the development of MEMS devices for radio frequency (RF) applications has been growing rapidly. RF MEMS devices have a broad range of potential applications in wireless communication, space, instrumentation, etc. The main failure analysis issue for RF MEMS metal contacting switches focuses on contact metallurgy. During passage of current through the switch contact, some portions of the interface may melt and weld due to high temperature and a molten metal might be splashed from the surfaces, which leads to device failure. In this study, a mathematical treatment of the general problem of electrical contacts and heating related to MEMS switch contacts is developed. The spatial distribution of the potential, the current and the temperature in a special case of electrical contact between two gold bodies whose thermal and electrical conductivities vary with temperature is analyzed, and an explanation for the collapse of gold contact system before reaching the melting point is given. For this purpose three different approaches are applied: 1) exact solution, 2) simple model approximation, and 3) variational calculus.
Citește tot Restrânge

Preț: 31064 lei

Puncte Express: 466

Preț estimativ în valută:
5498 6410$ 4763£

Carte tipărită la comandă

Livrare economică 27 februarie-13 martie

Preluare comenzi: 021 569.72.76

Specificații

ISBN-13: 9783659193088
ISBN-10: 3659193089
Pagini: 76
Dimensiuni: 152 x 229 x 5 mm
Greutate: 0.12 kg
Editura: LAP LAMBERT ACADEMIC PUBLISHING AG & CO KG
Colecția LAP Lambert Academic Publishing

Notă biografică

Reza Haj Mohammad Jafar holds a Master's degree in Mechanical Engineering from the University of Western Ontario and is currently pursuing a Ph.D. in Mechanical Engineering at University of Toronto. Dr. John R. Dryden is a Professor in the Department of Mechanical and Materials Engineering at the University of Western Ontario.
